    Asona Sonawood™ Panels

    Sonawood™ panels and Sonawood Slat™ are a made in NZ perforated wood panel with acoustic tissue backing designed to control unwanted noise in interior spaces. Panels may be customised according to substrate, decorative finish, acoustic perforations or slots and sized to meet individual project requirements. SlimSet 50™ and SlimSet 60™ Access Hatches are available where maintenance for plenum services is required.

    Application:
    Education
    Hospitality
    Commercial
    Recreation
    Form:
    Panel
    Direct Fix
    Fire Group:
    1-S - 3
    NRC Sound Absorption:
    0.50-0.70
    Made in NZ
    Colour / Finish
    Perforation
    Request Info/Spec Request Sample
    Description
    Specifications
    Downloads

    Sonawood™ perforated panels and Sonawood Slat™ are ideal for gymnasiums, sports centres, schools, spas, retail, hotels and corporate office buildings. Sonawood™ is available in large panel sizes or as a 600 x 1200mm tile for exposed grid ceiling systems.

    Sonawood™ panels offer a range of standard perforations for acoustic or aesthetic design options.  Sonawood Slat™ is designed to provide a continuous linear aesthetic design.

    Choice of plywood, FR plywood, or MDF & FR MDF substrates
    Selection of perforation patterns
    Selection of slat and slot widths
    Pre-finished low pressure laminates, natural veneer and plywood options with clear coat finish
    Fire Group 3, 2-S, 1-S performance subject to substrate open area selected
    Tuneable acoustic performance, open area 2.5 - 33%
    Range of fixing options, face fix, semi - concealed fix, split rail (walls)
    Asona in-house design service for shop drawings prior to manufacture
    Application:
    Education
    Hospitality
    Commercial
    Recreation
    Form:
    Panel
    Direct Fix
    Fire Group:
    1-S - 3
    NRC Sound Absorption:
    0.50-0.70

    Composition

    Manufactured options includes standard MDF and Plywood or fire rated MDF and Plywood with an integrated acoustic backing (IAB).

    Technical Datasheets

    Sonawood™ Panels

    Sonawood Slat™
    Installation Guides

    Sonawood™ Installation Guide
