    Asona Polyfon™ Pinboard

    Polyfon™ Pinboard is a fabric wrapped polyester wall panel available in a wide range of decorative fabric finishes. Polyfon™ Pinboard is designed for use in general office and the education environment where a tackable wall surface is required. Suitable for notice boards, meeting rooms, training rooms, classrooms and corridors etc.

    Application:
    Education
    Commercial
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.30-0.50
    Size:
    15 x 1200 x 1200 mm
    15 x 1200 x 1500 mm
    15 x 1200 x 2400 mm
    Request Info/Spec Request Sample
    Description
    Specifications
    Downloads

    Polyfon™ Pinboard is designed for use in general office and the education environment where a tackable wall surface is required. Suitable for notice boards, meeting rooms, training rooms, classrooms and corridors etc.

    Tackable wall finish
    Standard sheet sizes and custom sizes to order
    Available in a wide range of coloured fabric finishes
    Base board is compressed nude polyester for a superior flat finish
    Sound absorption rating to control reverberation up to NRC 0.50
    Global GreenTag Level B, Low VOC material. (nude polyester)
    Light weight
    Rigid panel can be fixed to studs or battens at 300mm centres or glue fixed over plasterboard lining
    Easy to trim and install
    Available to order, lead times 2-3 weeks
    Application:
    Education
    Commercial
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.30-0.50
    Size:
    15 x 1200 x 1200 mm
    15 x 1200 x 1500 mm
    15 x 1200 x 2400 mm

    Composition

    Manufactured from fire resistant high density polyester core and edge wrapped in fabric.

    Technical Datasheets

    Asona Polyfon™ Pinboard
